Apache Arrow + Polars + MinIO + Parquet Hive¶
MinIO
Github Repo
MinIO es una solución de almacenamiento de objetos compatible con S3 y de alto rendimiento, publicada bajo la licencia GNU AGPL v3.0. El almacenamiento de objetos es una tecnología especialmente adaptada para su utilización en el Data Lakehouse. Diseñada para ofrecer velocidad y escalabilidad, potencia la IA/ML, el análisis y las cargas de trabajo con un uso intensivo de datos con un rendimiento líder en el sector
Versión Arrow-Only¶
El código siguiente muestra cómo acceder utilizando únicamente la integración de Apache Arrow con Python a datos en un servidor S3 MinIO almacenados en formato Parquet y particionados al estilo Hive
import pyarrow as pa
import pyarrow.dataset as ds
import pyarrow.compute as pc
# Definir conexión a MinIO
minio = pa.fs.S3FileSystem(
endpoint_override='minio:9000',
access_key='YA9JokyWUb2hFUbKYEEN',
secret_key='0k2ornkQpVTqUrBbOEsEXOnBEEWgJf4AFQOU4O7Y',
scheme='http')
# Definir schema de los datos
schema = pa.schema([
pa.field("tts", pa.timestamp('us')),
pa.field("ServiceType", pa.string()),
pa.field("ServiceDate", pa.string()),
pa.field("ServiceTrain", pa.uint32()),
pa.field("StopCode", pa.string()),
pa.field("StopDepartureTime", pa.time64('us'), nullable=True),
pa.field("StopDepartureDelay", pa.int64(), nullable=True),
pa.field("StopArrivalTime", pa.time64('us'), nullable=True),
pa.field("StopArrivalDelay", pa.int64(), nullable=True),
pa.field("ns", pa.uint16())
])
# Crear dataset desde MinIO Hive Partitioned
ads = (
ds.dataset("labmtf/EuroTrain/",
filesystem=minio,
format="parquet", partitioning=ds.partitioning(schema=schema, flavor="hive"))
.filter(
pc.field('ServiceType').isin(
['EuroCity', 'Eurocity Direct', 'Eurostar', 'Nightjet', 'European Sleeper', 'ICE International']
)
)
)
# Convertir en tabla Arrow y presentar resultado como Pandas Dataframe
ads.to_table(
columns=["ServiceType", "ServiceDate", "StopCode", "StopArrivalTime", "StopDepartureTime"],
filter=pc.field("ServiceID") == "15070216"
).to_pandas()
| ServiceType | ServiceDate | StopCode | StopArrivalTime | StopDepartureTime | |
|---|---|---|---|---|---|
| 0 | EuroCity | 25-12-29 | ATW | 06:42:00 | 06:45:00 |
| 1 | EuroCity | 25-12-29 | BD | 07:18:00 | 07:26:00 |
| 2 | EuroCity | 25-12-29 | BERCH | 06:36:00 | 06:38:00 |
| 3 | EuroCity | 25-12-29 | BRUSC | 05:47:00 | 05:49:00 |
| 4 | EuroCity | 25-12-29 | BRUSN | 05:53:00 | 05:56:00 |
| 5 | EuroCity | 25-12-29 | BRUSZ | None | 05:44:00 |
| 6 | EuroCity | 25-12-29 | FBNL | 06:07:00 | 06:11:00 |
| 7 | EuroCity | 25-12-29 | MECH | 06:22:00 | 06:24:00 |
| 8 | EuroCity | 25-12-29 | NDKP | 06:59:00 | 07:01:00 |
| 9 | EuroCity | 25-12-29 | RTD | 07:50:00 | None |
Polars + Arrow: Scan a PyArrow dataset¶
A diferencia del ejemplo previo, en este se emplea un Polar LazyFrame para consultar los datos cargados desde MinIO mediante un pyarrow.dataset. En consecuencia, requiere añadir import polars
import pyarrow as pa
import pyarrow.dataset as ds
import pyarrow.compute as pc
import polars as pl
# Definir conexión a MinIO
minio = pa.fs.S3FileSystem(
endpoint_override='minio:9000',
access_key='YA9JokyWUb2hFUbKYEEN',
secret_key='0k2ornkQpVTqUrBbOEsEXOnBEEWgJf4AFQOU4O7Y',
scheme='http')
# Definir schema de los datos
schema = pa.schema([
pa.field("tts", pa.timestamp('us')),
pa.field("ServiceType", pa.string()),
pa.field("ServiceDate", pa.string()),
pa.field("ServiceTrain", pa.uint32()),
pa.field("StopCode", pa.string()),
pa.field("StopDepartureTime", pa.time64('us'), nullable=True),
pa.field("StopDepartureDelay", pa.int64(), nullable=True),
pa.field("StopArrivalTime", pa.time64('us'), nullable=True),
pa.field("StopArrivalDelay", pa.int64(), nullable=True),
pa.field("ns", pa.uint16())
])
# Crear dataset desde MinIO Hive Partitioned
ads = ds.dataset("labmtf/EuroTrain/", filesystem=minio, format="parquet", partitioning=ds.partitioning(schema=schema, flavor="hive")).filter(
pc.field('ServiceType').isin(['EuroCity', 'Eurocity Direct', 'Eurostar', 'Nightjet', 'European Sleeper', 'ICE International'])
)
lazy_df = (
# https://docs.pola.rs/api/python/stable/reference/api/polars.scan_pyarrow_dataset.html
pl.scan_pyarrow_dataset(ads).filter(pl.col("ServiceID") == "15070216").select(
["ServiceType", "ServiceDate", "StopCode", "StopArrivalTime", "StopDepartureTime"]
)
)
lazy_df.collect().to_pandas()
| ServiceType | ServiceDate | StopCode | StopArrivalTime | StopDepartureTime | |
|---|---|---|---|---|---|
| 0 | EuroCity | 25-12-29 | ATW | 06:42:00 | 06:45:00 |
| 1 | EuroCity | 25-12-29 | BD | 07:18:00 | 07:26:00 |
| 2 | EuroCity | 25-12-29 | BERCH | 06:36:00 | 06:38:00 |
| 3 | EuroCity | 25-12-29 | BRUSC | 05:47:00 | 05:49:00 |
| 4 | EuroCity | 25-12-29 | BRUSN | 05:53:00 | 05:56:00 |
| 5 | EuroCity | 25-12-29 | BRUSZ | None | 05:44:00 |
| 6 | EuroCity | 25-12-29 | FBNL | 06:07:00 | 06:11:00 |
| 7 | EuroCity | 25-12-29 | MECH | 06:22:00 | 06:24:00 |
| 8 | EuroCity | 25-12-29 | NDKP | 06:59:00 | 07:01:00 |
| 9 | EuroCity | 25-12-29 | RTD | 07:50:00 | None |
Versión Polars-Only: Scan Parquet (Hive Partitioning)¶
Este último ejemplo es Polars-Only, no hace falta nada más. Como en los ejemplos precedentes, el dataset se almacena particionado en un servidor de objetos S3 MinIO
import polars as pl
# Configuración del endpoint de MinIO y credenciales
storage_options={"aws_access_key_id": "YA9JokyWUb2hFUbKYEEN",
"aws_secret_access_key": "0k2ornkQpVTqUrBbOEsEXOnBEEWgJf4AFQOU4O7Y",
"endpoint_url": "http://minio:9000"
}
s3url = "s3://labmtf/EuroTrain/**/*.parquet"
# Dafinir LazyFrame
lazy_df = (
pl.scan_parquet(s3url, storage_options=storage_options, hive_partitioning=True)
.filter(pl.col("ServiceID") == "15070216")
.select(["ServiceDate", "ServiceType", "StopCode", "StopArrivalTime", "StopDepartureTime"])
)
# Realizar operaciones y recolectar resultados
df = lazy_df.collect()
# Mostrar metadatos
print(df.glimpse(return_type="frame"))
# Mostrar resultado
df.to_pandas()
┌───────────────────┬───────┬─────────────────────────────────┐
│ column ┆ dtype ┆ values │
│ --- ┆ --- ┆ --- │
│ str ┆ str ┆ list[str] │
╞═══════════════════╪═══════╪═════════════════════════════════╡
│ ServiceDate ┆ str ┆ ["'25-12-29'", "'25-12-29'", …… │
│ ServiceType ┆ str ┆ ["'EuroCity'", "'EuroCity'", …… │
│ StopCode ┆ str ┆ ["'ATW'", "'BD'", … "'RTD'"] │
│ StopArrivalTime ┆ time ┆ ["06:42:00", "07:18:00", … "07… │
│ StopDepartureTime ┆ time ┆ ["06:45:00", "07:26:00", … nul… │
└───────────────────┴───────┴─────────────────────────────────┘
| ServiceDate | ServiceType | StopCode | StopArrivalTime | StopDepartureTime | |
|---|---|---|---|---|---|
| 0 | 25-12-29 | EuroCity | ATW | 06:42:00 | 06:45:00 |
| 1 | 25-12-29 | EuroCity | BD | 07:18:00 | 07:26:00 |
| 2 | 25-12-29 | EuroCity | BERCH | 06:36:00 | 06:38:00 |
| 3 | 25-12-29 | EuroCity | BRUSC | 05:47:00 | 05:49:00 |
| 4 | 25-12-29 | EuroCity | BRUSN | 05:53:00 | 05:56:00 |
| 5 | 25-12-29 | EuroCity | BRUSZ | None | 05:44:00 |
| 6 | 25-12-29 | EuroCity | FBNL | 06:07:00 | 06:11:00 |
| 7 | 25-12-29 | EuroCity | MECH | 06:22:00 | 06:24:00 |
| 8 | 25-12-29 | EuroCity | NDKP | 06:59:00 | 07:01:00 |
| 9 | 25-12-29 | EuroCity | RTD | 07:50:00 | None |
